CL-1212
Kafan
Availability: | |
---|---|
Cyclone blast cabinets are designed for cleaning and finishing with dry abrasive such as glass beads, aluminum oxide, garnet, sands, etc. It produces varous different finishes such as rust-removing, smoothing, decorating, etc, depending on the type of medias and the air pressure used.
Cyclone blaster especially works well when applying ultra fine medias even up to 220 mesh, whose purpose is to get a fine and effective finish.
While using ultra fine abrasives, they are easily mixed with the dust particles and collected to the cartridge filter. The cyclone device is better for separating micro abrasive and dust, enables the filter only collect the dust and creates a high recycle rate of abrasive, reduce consumption and save cost. If you use very fine or light abrasive for blasting, the cyclone blasting system is the initial choice.
1. Except cyclone separator, there is a filter dust collector with fan that effectively collects dust, ensures clear working chamber.
2. Abrasives can be recycled for many times, a great saving of production expense
3. The blasting gun working is controlled by foot switch, offers safety and reduce operator's fatigue
4. Our sandblaster machine is durable steel plate welded, whose surface is powder coated, sturdy and wear-resistance.
5. One year warranty, only requires simple electric and pneumatic connection when you receive the blaster before use.
Model | CL-1212A Sandblasting System |
Outside Size | L1620*W1200*H1800mm |
Cabin Size | L1200*W1200*H800mm |
Max.Loading | 100-500kgs as request |
Number of gun | 1 (boron carbide nozzle) |
Power Supply | 110V/220V/380V/410V/450V/(50-60Hz) |
Separator motor | 0.75kw |
Lighting | 18w fluorescent |
Air source requirement:: | pressure 7bar (kg / square meter) |
Other | 0.8-1.2 m3 / min |
Model | Outer Dimension(L*W*Hmm) | Working Dimension(L*W*Hmm) |
CL-6050 | 830*600*1500 | 600*500*650 |
CL-7050 | 930*700*1500 | 700*500*650 |
CL-9060 | 1030*900*1650 | 900*600*650 |
CL-9080 | 1230*900*1700 | 900*800*800 |
CL-1010 | 1430*1100*1800 | 1000*1000*800 |
CL-1212 | 1620*1300*1800 | 1200*1200*800 |
Kafan has 10+ years of industry experience and knowledge for surface finishing equipment. We know how to produce powerful high quality sandblasting with friendly.budget Our sandblasters are constructed from high quality steel and carefully assembled, and coated with plastic powders, ensure durability and long lifespan. Electic or pneumatic components are from famous brand ensure reliability. Each product that leaves our facility must pass a strict quality inspection. Before or after sale service is a 24h phone call or email to help you.
Cyclone blast cabinets are designed for cleaning and finishing with dry abrasive such as glass beads, aluminum oxide, garnet, sands, etc. It produces varous different finishes such as rust-removing, smoothing, decorating, etc, depending on the type of medias and the air pressure used.
Cyclone blaster especially works well when applying ultra fine medias even up to 220 mesh, whose purpose is to get a fine and effective finish.
While using ultra fine abrasives, they are easily mixed with the dust particles and collected to the cartridge filter. The cyclone device is better for separating micro abrasive and dust, enables the filter only collect the dust and creates a high recycle rate of abrasive, reduce consumption and save cost. If you use very fine or light abrasive for blasting, the cyclone blasting system is the initial choice.
1. Except cyclone separator, there is a filter dust collector with fan that effectively collects dust, ensures clear working chamber.
2. Abrasives can be recycled for many times, a great saving of production expense
3. The blasting gun working is controlled by foot switch, offers safety and reduce operator's fatigue
4. Our sandblaster machine is durable steel plate welded, whose surface is powder coated, sturdy and wear-resistance.
5. One year warranty, only requires simple electric and pneumatic connection when you receive the blaster before use.
Model | CL-1212A Sandblasting System |
Outside Size | L1620*W1200*H1800mm |
Cabin Size | L1200*W1200*H800mm |
Max.Loading | 100-500kgs as request |
Number of gun | 1 (boron carbide nozzle) |
Power Supply | 110V/220V/380V/410V/450V/(50-60Hz) |
Separator motor | 0.75kw |
Lighting | 18w fluorescent |
Air source requirement:: | pressure 7bar (kg / square meter) |
Other | 0.8-1.2 m3 / min |
Model | Outer Dimension(L*W*Hmm) | Working Dimension(L*W*Hmm) |
CL-6050 | 830*600*1500 | 600*500*650 |
CL-7050 | 930*700*1500 | 700*500*650 |
CL-9060 | 1030*900*1650 | 900*600*650 |
CL-9080 | 1230*900*1700 | 900*800*800 |
CL-1010 | 1430*1100*1800 | 1000*1000*800 |
CL-1212 | 1620*1300*1800 | 1200*1200*800 |
Kafan has 10+ years of industry experience and knowledge for surface finishing equipment. We know how to produce powerful high quality sandblasting with friendly.budget Our sandblasters are constructed from high quality steel and carefully assembled, and coated with plastic powders, ensure durability and long lifespan. Electic or pneumatic components are from famous brand ensure reliability. Each product that leaves our facility must pass a strict quality inspection. Before or after sale service is a 24h phone call or email to help you.
1. Pretreatment of electroplating, paint spraying, coating, etc. to completely clean the surface and improve the adhesion and anti-corrosion ability.
2. Cleaning the mill scale/residues/dirt of casting/pressing /welding/heat treatment work piece, cleaning the surface of non-metal items, cleaning the black spots on the ceramic embryo surface, restoring paint grain pattern, etc.
3. Refurnishing sports part of car, motorcycle, electromechanical device, etc., eliminating fatigue stress and extending working life.
4. Removing surface marks of metal/non-metal items, dumb face and fog treatment processing to enhance the product grade.
5. Dumb face and fog treatment of mould, text composition, mould cleaning without damage to the mould.
6. Removing the tiny burrs of mechanical parts and injection plastic parts.
7. Removing unqualified covering,color and printing of products.
8. Enhancing the surface hardness of metal work piece and eliminating stress, such as processing plane vane, spring, machining knife, weapons etc.
9. Carving patterns/words and slip resistance treatment on the surface of metal and non-metal items, such as marble, handle anti-skid, stamping, stele lettering, etc.
10. Sandblasting/white mark/cat’s whisker effect treatment of jeans wear.
